CAM Superline 7×21 Low Profile Split-Tilt Equipment Trailer

CAM Superline 7×21 Low Profile Split-Tilt Equipment Trailer

The CAM Superline 7×21 Low Profile Split-Tilt Equipment Trailer is designed to make loading and transporting compatible construction, landscaping, agricultural and commercial equipment easier. Instead of relying on conventional loading ramps, this trailer features a split-tilt deck with an adjustable hydraulic cushion cylinder.

Its 21-foot deck consists of a 4-foot stationary section and a 17-foot tilting section, giving operators a practical loading platform while retaining a stationary front deck area. The low-profile configuration also helps create a more manageable loading angle for compatible machinery.

CAM Superline 7×21 Split-Tilt Trailer Specifications

• Manufacturer: CAM Superline
• Trailer Type: Low Profile Split-Tilt Equipment Trailer
• Deck Width: 80″
• Deck Length: 21′
• Stationary Deck: 4′
• Tilt Deck: 17′
• Axles: (2) 7,000-lb Dexter Leaf Spring Axles
• Brakes: Electric Brakes on All 4 Wheels
• Tires: 235/80R16
• Coupler: Adjustable 2-5/16″ Ball Coupler
• Jack: 12K Drop-Leg Jack
• Tilt System: Adjustable Hydraulic Cushion Cylinder
• Cargo Securement: Stake Pockets and D-Rings
• Storage: Aluminum Toolbox
• Additional Features: Approach Plate, Pallet Fork Carrier and Spare Tire Mount
• Warranty: Two-Year Warranty

17-Foot Hydraulic Tilt Deck

The standout feature of this CAM Superline tilt equipment trailer is its 17-foot tilting deck. The tilt design can eliminate the need to manually position conventional loading ramps for many applications, making repeated loading and unloading more convenient.

An adjustable hydraulic cushion cylinder controls the movement of the tilting deck. The approach plate helps provide a smoother transition from the ground onto the trailer deck for compatible wheeled or tracked equipment.

4-Foot Stationary Front Deck

The split-tilt configuration includes a 4-foot stationary front deck. This gives operators a non-tilting section at the front while the remaining 17 feet serves as the primary tilt-loading platform.

This design makes the trailer especially useful for contractors and equipment operators who regularly load machinery but still want stationary deck space.

Tandem 7,000-Lb Dexter Axles

This CAM Superline equipment trailer is equipped with two 7,000-lb Dexter leaf spring axles. The tandem-axle configuration provides a heavy-duty foundation for demanding equipment-hauling applications.

Electric brakes are installed on all four wheels to provide additional braking assistance when connected to a properly equipped tow vehicle and compatible brake controller.

Heavy-Duty Equipment Loading

The combination of the low-profile deck, hydraulic tilt system and approach plate makes this trailer suitable for loading many types of compatible machinery. Depending on equipment dimensions, weight and the trailer’s certified payload rating, possible applications include:

• Skid steers
• Compact tractors
• Mini excavators
• Commercial lawn equipment
• Landscaping machinery
• Construction equipment
• Utility vehicles
• Agricultural equipment

Cargo Securement Features

Integrated D-rings and stake pockets provide multiple options for properly securing equipment and cargo. Operators should always use appropriately rated chains, straps and binders based on the equipment being transported.

The trailer also includes a pallet fork carrier, making it especially useful for operators who transport machinery together with compatible attachments.

Aluminum Toolbox and 12K Drop-Leg Jack

An integrated aluminum toolbox provides convenient storage for hauling accessories, straps and other equipment. The heavy-duty 12K drop-leg jack provides front-end support while the trailer is parked or being connected to a compatible tow vehicle.

CAM Superline Tilt Equipment Trailer for Sale

If you’re searching for a CAM Superline 7×21 tilt equipment trailer for sale, this model combines a versatile split-tilt design with tandem Dexter axles, electric brakes and practical equipment-hauling features.

Always confirm the trailer’s VIN/data plate, GVWR, empty weight and rated payload before determining whether a particular machine can safely be transported.
